NBF-32026 by Bud Industries Weatherproof Enclosure Precision Cut 32 Pigtail Holes 5 RJ45 Holes

Common Accessories

  • NBF-32026 by Bud Industries Weatherproof Enclosure Precision Cut 32 Pigtail Holes 5 RJ45 Holes
  • NBF-32026 Mounting Plate Kit for Falcon or Kulp Controllers
  • Total Together: $116.00

NBF-32026 by Bud Industries Weatherproof Enclosure Precision Cut 32 Pigtail Holes 5 RJ45 Holes

$71.00

NBF-32026 by Bud Industries Weatherproof Enclosure Precision Cut 32 Pigtail Holes 5 RJ45 Holes

This option does not exist.

Availability:In Stock
Model: ennbf32026-32
MFG Part#: NBF-32026
Condition: New
Operating Weight: 4.0625 lbs
Shipping Weight: 5.126 lbs
Shipping Dimensions: 16" × 13" × 7"


Share:

Product Overview

The NBF-32026 is a great option to mount controllers and other peripherals in a water resistant box. We carry a mounting plate that will work with both Falcon and Kulp style controllers while housing up to four power supplies. This precision, pre-cut version was designed to house a Kulp K16A-B with string expansion or differential expansion, a Kulp K32A-B, a Falcon F16 v2/v3/v4/v5 with string expansion and differential expansion, or a EL GPX32 Pro. The box comes pre-cut with 32 PG7 sized holes for pigtails of your choice, two PG9 sized holes for power, and 5 holes for RJ45 passthrough glands to allow for network connectivity and receiver boards

Want some help building a full controller? Check out our Build-A-Kit page for controllers. It will assist you in finding all the items you need for a full controller buildout https://www.wiredwatts.com/build-a-controller-kit

Product Specifications

  • External Dimensions: 15.75" × 11.81" × 6.30"
  • Internal Dimensions: 14.73" × 10.79" × 5.69"
  • Weight: 5.6 lbs
  • Color: Light Gray
  • Indoor / Outdoor: Indoor (Not UV Stabilized)
  • Flammability Rating: UL94-HB
  • Type of Plastic: ABS
  • Service Temperature Min: -40°C
  • Service Temperature Max: 60°C
  • IP Rating: 66
